Featuring 1198 channels of tracking all running and planned constellations, enhanced UHF for up to 15km working range, improved high precision IMU, low power consumption and over 24 hours working time, the N3 receiver making it work-efficient and energy-saving for your survey tasks.
Online customer service
Support GPS, BDS-2, BDS-3, GLONASS, Galileo, QZSS and SBAS tracking.
25 hours long-lasting batteries.
Up to 15km work range with 2W power consumption with enhanced UHF
IP67 water and dust proof level for harsh environments.
Improved IMU of simpler initialization and high accuracy.
Industry-leading 1.7W low power consumption.
Powerful web UI to easily download static data & upgrade firmware.
Support WiFi/4G/Bluetooth/UHF transmission.
Enhanced UHF: Up to 15km long work range with 2W power consumption, making it work-efficient and energy-saving for your survey tasks. Integrated UHF ranges from 410 to 470 MHz with 12.5 KHz channel spacing.
Upgraded IMU: Adopted the improved INS algorithm, the second generation of IMU obtains simpler initialization process and 2cm high accuracy.
New K8-platform: Integrated with new K8-platform, N3 equipped with powerful tracking capability for more than 50 satellites, stronger computing capability and lower power consumption.

• 1198 Channels SinoGNSS Quantum Engine Board
• Satellite signals tracked: GPS(USA), GLONASS(Russia), GALILEO(Europe), BEIDOU(China), IRNSS(India), QZSS(Japan)
• Triple Frequency
• IMU & Tilt compensation technology
• Static, RTK, Supports long Baseline E-RTK , Compatible with any CORS
• Base/Rover Internet communication, No baseline limitation
• Static horizontal/vertical accuracy: 2.5mm +/5mm + 0.5ppm
• RTK horizontal/vertical accuracy: 8mm/15mm + 1ppm
• RTK formats CMR, CMR+, RTCM 2.x, RTCM 3.x
• RS232, Bluetooth, USB, GSM, GPRS, EDGE ,WebUI
• Internal/External UHF Radio, 15km baseline with internal radio
• Voice messages, Automatic Firmware updating
• 8GB internal & up to 32 GB pluggable memory
• Swappable internal batteries 2x3400mAh up to 25hrs typically
• Rugged magnesium-aluminum alloy housing to survive 2m drop on concrete
• Dust & weather resistant, IP67
• Data collector R550 with Android Survey Master Field Software
• Support other data collection software; FieldGenius, Carlson SurvCe
• Light weight; 950gms with two batteries
• Small in size; 158mm diameter and 75mm height

Package Details

• 1x Comnav N3 Rover Receiver Set
• 1x Comnav R60 Data Collector Set+ Survey Master Field Software
• 1x G61102 Pole clamp+vial+compass
• 1x G61207 Quick Release cradles
• 1x G61009 Snap-Lock Rover Rods 2m
